After 11 years and more and more than 400 completed frames in our frame building course, I am really happy to announce our new course in building your own stainless steel road or gravel frame. Your stainless frame will be built within the framework of the Fillet Brazed frame building course, however for your frame we will mostly be using Columbus XCR stainless steel tubing. Your frame will be brazed with Silver, which is required for stainless steel. Once you get the hang of it, brazing with silver is easier than brass. It is also easier to file and sand, which sets you up to perhaps actually achieve the frame you’ve been dreaming of building yourself. The course takes 5 days like most of our courses, costs 2250 Euro, and the material cost is around 1500 Euro.
To register for a course just fill out the form below, to complete the reservation I require a 500 Euro deposit. Or, if you prefer, just send me an e-mail, also if you have any questions, to info@bigforestframeworks.com, and I can send the bill for the deposit via email.
Challenges
To build your own frame takes just 5 days in our workshop in Potsdam, Germany. Here's what your (first) week will look like...
DAY 1 - Geometry, Tube Selection, Getting Started
The planning for your new bike usually starts a few months before your course starts, normally we have a rough draft of the geometry before you arrive. Monday morning starts with a coffee and a chat about the bike you’d like to build, so everyone is on the same page. Then we’ll test out the geometry of your new bike on the frame-sizer, and perhaps do a bit of fine tuning so it really fits you right. After a bit of practice with basic metal work skills, we’ll get started mitering the main tubes in the afternoon.
DAY 2 - Main Tube Mitering, Bottle Boss Brazing
Usually we start day 2 with your introduction to brazing. We’ll braze two tubes together, and try to break the joint (which never happens!). This will give you the confidence you need to know that what you’re creating is actually going to hold together. When the main tubes are mitered, you’ll put them in the frame jig and do a bit of fine tuning so that everything fits how it needs to. Now it’s about to get hot! We will drill the holes for the bottle bosses and braze them in the tubes.
DAY 3 - Chain Stay Prep & Dropout Brazing
We’ll get started on the chain stays. They usually need to be bent for crank arm clearance, pressed for chain ring and tire clearance, and slotted to accept the dropouts. Perhaps we also need some holes, if the cables are guided internally. After getting everything fit up, we’ll braze the chain stays to the dropouts, and then they are mitered at the same time to the bottom bracket. With the front triangle finished, we’ll check the chain stay fit, which might need a bit of fine tuning. Now you’re ready to tack the frame in the jig! After tacking, the frame is brazed, and now you’re ready for a good night’s sleep.
DAY 4 - Brazing the frame, checking alignment
After brazing we need to chase and face the bottom bracket, so we can check the frame alignment. The heat from the torch causes a bit of distortion, and the frame needs to be straightened. It’s actually a pretty simple process when you have the right tools. Then we get started on the seat stays, they are mitered to the seat tube, shortened and slotted at the dropout side, and brazed in place. Now your dream is really becoming reality! We aren’t done yet, but the end is in sight!
DAY 5 - Finish Work, Details, Sanding
Friday, last day! Depending on which type of bike you are building, you might need or want bridges between the seat and chain stays to increase the stiffness of the frame or so you can easily mount fenders. Perhaps you need bosses to attach a rack as well. The seat tube and head tube need to be reamed, you need a slot in the seat tube, and a drain hole in the bottom of the bottom bracket. At last comes the frame number! You can choose your own frame number, up to 9 letters or numbers. It is stamped in a piece of brass, and we braze it to the frame. And you can also braze one of our small brass trees to the frame if you like as well. That’s it, you did it!!!
It could be yours...
Did you ever think about building your own bike frame?
Join our newsletter and connect with fellow frame building enthusiasts! Get essential tips and tricks, be inspired by our 'Bike of the Month,' and discover exciting bikepacking and cycling adventures you won't want to miss!
Who We Are
At Big Forest Frameworks it takes a team of three to make your dream become reality.
Robert.
Founder and visionär Robert Piontek is still teaching courses after more than 10 years at Big Forest Frameworks. His dream started just like yours. Bored at work and wanting to do something different, he took the plunge and managed to build a lugged fixed gear frame. He finally found what he was looking for, the experience of creating, which had been missing from his life for far too long.
Konrad.
Master mechanic and the frame builder behind many of the bikes you‘ve seen here recently, Konrad has been working in the bike business for more than 25 years. In his earlier days he raced road and CX at the highest level in Germany. He also owned and ran his own bike shop for many years, before joining Big Forest Frameworks in 2022.
You.
That’s right, you! Our team wouldn’t be complete without you! Our course participants are looking to get away from the daily grind of their day jobs in front of the computer. They want to experience the pleasure of building their own frame, creating something with their own hands, that they will enjoy for a lifetime to come!
